Home > Stainless Steel > Stainless Steel 420 Tubing
Impextubeind, one of the renowned Mumbai-based manufacturer and supplier of high-quality products, provides top-notch Stainless Steel 420 Tubing suitable for uses requiring strength, hardness, and average corrosion resistance. Precision engineering and industrial applications are ideal for these tubes due to the requirement of machinability and strength. Supplied in diverse sizes, thicknesses, and finishes, Impextubeind’s SS 420 tubing adheres to both national and international standards. With emphasis on on-time delivery of quality products, we serve various industries such as automotive, medical, tool manufacturing, and food processing, guaranteeing consistent performance in high-stress applications.
Stainless Steel 420 Tubing is a martensitic stainless steel type mostly made up of 12–14% chromium and at least 0.15% carbon, which makes it capable of being heat-treated for greater hardness and strength. It contains little nickel and is magnetic in annealed as well as hardened form. Mechanical characteristics are tensile strength of 700–850 MPa, yield strength approximately 345 MPa, and elongation of up to 20%. It also presents satisfactory ductility and wear resistance, with normal corrosion resistance increasing with surface treatment and heat treating, and finding use in exacting structural and precision applications.
Item | Stainless Steel 420 Tube |
Standard | GB, AISI, ASTM, ASME, EN, BS, DIN, JIS |
Type | Seamless / ERW / Welded / Fabricated / CDW |
Outer Diameter Size | SEAMLESS – 1/2″ NB TO 18″ NB WELDED / ERW- 1″ NB TO 16″ NB EFW – 8″ NB TO 110″ NB |
Form | 420 Round Tubing, 420 Square Tubes, 420 Rectangular Tube, “U” Shape 420 Tubing, 420 Hydraulic Tubes |
Wall Thickness | Schedule 10 To Schedule 160 (3 mm to 100 mm Thickness) |
Length | 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size End: Plain End, Beveled End, Treaded |
Delivery Conditions | As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered, Cold Draw |
Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated |
Testing | Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiographic Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc |
Dimension | All Tubes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME |
Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
| Grade | C | Mn | Si | P | S | Cr | |
|---|---|---|---|---|---|---|---|
| 420 | Min. max. | 0.15 – | – 1 | – 1 | – 0.040 | – 0.03 | 12.0 14.0 |
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50mm) | Hardness Brinell (HB) | Impact Charpy V (J) |
|---|---|---|---|---|---|
| Annealed * | 655 | 345 | 25 | 241 max | – |
| 204 | 1600 | 1360 | 12 | 444 | 20 |
| 316 | 1580 | 1365 | 14 | 444 | 19 |
| 427 | 1620 | 1420 | 10 | 461 | # |
| 538 | 1305 | 1095 | 15 | 375 | # |
| 593 | 1035 | 810 | 18 | 302 | 22 |
| 650 | 895 | 680 | 20 | 262 | 42 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 420 Tubing from Impex Tube India ensures high quality and durability, as these pipes offer excellent corrosion resistance and strength. Our commitment to exceptional service and reliable delivery guarantees customer satisfaction across various industrial applications. Our expertise in stainless steel products ensures you receive a top-tier solution tailored to your needs.
Impex Tube India, one of the largest suppliers of Stainless Steel 420 Tubing in Mumbai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel 420 Tubing to meet your specific requirements. Our team at Impex Tube India is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@impextubeind.com.
Stainless Steel 420 Tubing is extensively applied in applications demanding high mechanical strength, hardness, and wear resistance. It is frequently utilized in the production of surgical instruments, cutting tools, and medical equipment because of its high edge retention and polishability. In the automobile sector, it is utilized in shafts, fuel lines, and structural components. The food processing industry takes advantage of SS 420 tubing for equipment and utensils that need to be clean and resistant. It is also suitable for pump shafts, valves, and parts of industrial machinery. Although not for very corrosive or marine conditions, it works well in dry or mildly corrosive environments.
