Impex Tube India, Mumbai, India is a prominent trader of high quality steel products specializing in Duplex Steel Pipes. We supply pipes manufactured from highest quality Duplex Steel grades including UNS S31803 and S32205 famous for their immense strength and higher corrosion resistance. We offer these pipes in forms of round, square, and rectangular shapes to bear extreme pressures and harsh climatic conditions. A high level of concern for quality and accuracy, Impex Tube India guarantees reliable, durable, cost-efficient piping solutions to numerous applications across industry.
Duplex Steel Pipes comprise mostly of 22% Chromium, 5-6% Nickel, 3% Molybdenum, and 0.2% Nitrogen and feature exceptional corrosion and tensile strengths. Properties mechanically comprise a high yield strength of approximately 450 MPa as well as a tensile strength of up to 700 MPa, displaying excellent resistance towards stress corrosion cracking and fatigue. Physically, Duplex Steel has a density of 7.8 g/cm³, melting point of 1350°C, as well as a thermal conductivity of 19 W/m·K, which make it suitable for high-pressure as well as demanding environmental applications.
| Standard | ASTM A790 / ASME SA790 UNS S31803, S32205, S32550, S32750, S32760 |
| Materials | ASTM A815 – UNS S31803 |
| Size | 1/2″NB TO 12 “NB IN |
| Seamless Pipes & Tubes Sizes | 1/2” NB – 8” NB |
| Welded Pipes & Tubes Sizes | 6” NB – 24” NB |
| Thickness | 0.5-45mm |
| Outer Diameter | 6.0-630mm |
| Dimensions | OD(6.0-630)*WT(0.5-45)mm |
| Schedule | SCH20, SCH30, SCH40, STD, SCH80 |
| Type | Welded / Fabricated / Seamless |
| Length | Single Random, Double Random & Cut Length. |
| Ni | Cr | Mo | Mn | Si | C | N | S | P | Fe | |
| MIN | 4.5 | 22.0 | 3.0 | – | – | – | 0.14 | – | – | – |
| MAX | 6.5 | 23.0 | 3.5 | 2.0 | 1.0 | 0.03 | 0.2 | 0.02 | 0.03 | Balance |
| S31803 / S32205 | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Duplex Steel Pipes by Impex Tube India assures top class quality and endurance. These pipes are most famous for their exceptional corrosion resistance and high durability. With our relentless pursuit for best service and timely delivery, we commit to customer satisfaction in various industrial uses. Based on our vast experience in stainless steel items, we deliver customized solutions according to your precise demands, providing the best-in-class performance and dependability.
Impex Tube India is among the biggest Mumbai-based suppliers of Duplex Steel Pipes in India. They have an extensive range of pipes and tubes made from top-quality materials ideal for use in a variety of industries. The company’s large stock and excellent service quality make them the most preferred supplier of stainless steel products in India.
Yes, we provide custom sizes for Duplex Steel Pipes to suit your individual needs. Our staff at Impex Tube India is dedicated to delivering personalized solutions for all your Piping & tubing requirements. For more information, call us at sales@impextubeind.com.
| Nominal pipe size up to 4 = ± 0.79 mm | 5 thru 8 = + 1.58 mm / – 0.79 mm 10 thru 18 = + 2.37 mm / – 0.79 mm | 20 thru 24 = + 3.18 mm / – 0.79 mm | ||
| Wall Thickness All Diameters = – 12.5% + tolerance not specified | Length + 6.40 mm / – 0 mm | Weight Weight = + 10% / – 1.5% |
| Wall | Sizes ( O.D.) |
|---|---|
| .010 | 1/16″ , 1/8″ , 3/16″ |
| .020 | 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″ , 3/16″ |
| .028 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″ |
| .035 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .049 | 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .065 | 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″ |
| .083 | 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″ |
| .095 | 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .109 | 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .120 | 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″ |
| .125 | 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″ |
| .134 | 1″ |
| .250 | 3″ |
| .375 | 3 1/2″ |
Duplex Steel Pipes are widely applied in high-strength and corrosive-resistant processes. They suit oil and gas, chemical process, marine, and power industries, particularly in offshore platforms, heat exchanger, and pressure vessels. They are also most suitable for pulp and paper factories, water treatment plants, and desalination plants because they are resistant to stress corrosion cracking. Additionally, Duplex Steel Pipes are commonly used in petrochemical industries, chemical tanks, and high-pressure piping systems, which provide long-lasting performance in aggressive, high-stress environments.
