Impex Tubes India is a leading manufacturer and supplier of pipes and tubes of high quality, located in Mumbai, India. Impex Tubes India is recognized for its cutting-edge manufacturing methods and dedication to producing high-quality products, such as Aluminium Coil Tubing. With a focus on performance and durability, Aluminium Coil Tubing by Impex Tubes India finds extensive use in many industries due to its flexibility, corrosion resistance, and simplicity of installation. With an emphasis on delivering global quality standards, the company exports its aluminium tubing to domestic as well as international markets, providing reliable solutions for various industrial uses.
Aluminium Coil Tubing is typically produced from alloys like 3003 or 6061, consisting of primarily aluminum (over 96%) supplemented by elements such as manganese, magnesium, and silicon for strength and corrosion resistance. These tubings have very good mechanical properties, such as tensile strength of between 130 MPa and 310 MPa based on the alloy and temper. They also have good elongation and flexibility, making them suitable for coiled applications. The alloy is non-heat treatable in certain grades such as 3003, although other grades such as 6061 are heat-treatable to enhance strength. The blend provides durability, formability, and long-enduring performance.
Standards : ASTM B345, B241, B429 / ASME SB345, SB241, SB429
Standard : AMS QQ-A-200/8, AMS QQ-A-200/9, AMS 4160/4161/4172
Size : 8 (1-1/2″ / 1.900″)
Outer Diameter : 1″ through 16″
Length : Double Random, Single Random, Cut Length
Thickness : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
End : Plain End, Beveled End, Threaded
ASTM B429 / ASME SB429 – Standard Specification for Aluminum-Alloy Extruded Structural Tube and Tube
EN AW-AlMg1SiCu – Standard Specification for Aluminum and Aluminum-Alloy Round Tube
ISO AlMg1SiCu – Standard Specification for Aluminum and Aluminum-Alloy Cold / Hot Rolled Tubing
| Alloy | Fe | Si | Mg | Mn | Cu | Zn | Ti | Cr | Others | AI |
| 1100 (min) | 0.35 | 0.25 | 0.01 | 0.01 | 0.05 | 0.01 | 0.020 | Trace | 0.05 (each) | 99.60% |
| 1100 (max) | 0.50 | 0.35 | 0.03 | 0.05 | 0.20 | 0.05 | 0.030 | Trace | 0.15 (total) | remainder |
| 5083 | 0.40 max | 0.40 max | 4.0 / 4.90 | 0.40 / 1.0 | 0.10 max | 0.25 max | 0.15 max | 0.05 / 0.25 | 0.05 max | Bal |
| 6061 | 0.7 | 0.4-0.8 | 0.8-1.2 | 0.15 | 0.15-0.4 | 0.25 | 0.15 | 0.15-0.35 | 0.005/0.15 | Remainder |
| 6068 | 0.50 max | 0.7 – 1.3 | 0.06-1.20 | 0.40-1.00 | 0.10 max | 0.20 max | 0.10 max | 0.25 max | 0.05 max | Bal |
| 7075 min | 2.10 | 1.20 | 5.10 | 0.18 | ||||||
| 7075 max | 0.50 | 0.40 | 2.90 | 0.30 | 2.00 | 6.10 | 0.20 | 0.28 | 0.05 |
| Alloy | Temper | UTS(Mpa) | % Elongation | Tensile Strength | Hardness Brinell | Proof Stress | Yield Strength (PSI) | Shear Strength (PSI) | Brinell Hardness | |||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | ||||||||
| 1100 | O | 75 | 110 | 20 | 25 | 29 | ||||||
| H12 | 95 | 130 | 5 | 6 | 7 | |||||||
| H14 | 110 | 145 | 3 | 4 | 5 | |||||||
| H16 | 130 | 165 | 2 | 3 | 4 | |||||||
| H18 | 150 | — | 2 | 2 | 3 | |||||||
| 5083 | 12 Min % | 275 – 350 MPa | 75 HB | 125 Min MPa | ||||||||
| 6061 | – | 45,000 | 12 | 40,000 | 31,000 | 95 | ||||||
| 6082 | 8 | 295 | 95 | – | 240 | – | – | |||||
| 7075 T6, T651 | 11 | 83-572 | 73- 503 | 150 | ||||||||
| 7075 T73, T7351 | 13 | 73-503 | 63-434 | NA | ||||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Aluminium Coil Tubing from Impex Tube India ensures high-quality, reliable performance for various industrial applications. As a trusted manufacturer and supplier in Mumbai, India, Impex Tube India offers precision-engineered aluminium coil tubing known for its exceptional strength, corrosion resistance, and lightweight properties. The company adheres to strict quality standards, providing durable, long-lasting products that meet industry specifications. With a commitment to customer satisfaction, prompt delivery, and technical support, Impex Tube India is the ideal choice for your aluminium coil tubing needs.
Impex Tube India, one of the largest suppliers of Aluminium Coil Tubing in Mumbai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Aluminium Coil Tubing to meet your specific requirements. Our team at Impex Tube India is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@impextubeind.com.
| Grade | UNS | USA | Japan | France | ISO | WNR | EN | DIN | ISO | BS (OLD) |
| 1100 | A91100 | AA1100 | JIS A1100P | NF 1100 | Al 99.0 Cu. | – | – | – | – | – |
| 6082 | A96082 | AA6082 | – | – | – | 3.2315 | AW-6082 | AlMgSi1 | AlSi1MgMn | HE30 |
| 5083 | A95083 | 5083 | – | – | AlMg4,5Mn0,7 | 3.3547 | AW-AlMg4,5Mn0,7 | AlMg4,5Mn | – | – |
| 6061 | A96061 | AA6061 | – | – | – | 3.3211 | AW-AlMg1SiCu EN AW-6061 | AlMgSiCu | AlMg1SiCu | HE20 |
| 7075 | A97075 | 7075 | 3.4365 | ENAW-AlZn5.5MgCu EN AW-7075 | AlZnMgCu1.5 | AlZn6MgCu | 7075 L95 L96, V95 |
Aluminium Coil Tubing finds extensive application in industries where flexibility, corrosion resistance, and light weight are crucial. In the refrigeration and HVAC industries, it is used extensively for fluid transfer lines, evaporators, and condensers because of its high thermal conductivity and anti-corrosive properties. It is also used extensively in automotive and aerospace applications for fuel and brake lines. In building, it is used in plumbing systems, solar panel piping, and compressed air piping. It is easy to transport and install because of its coil configuration, particularly in confined or complicated areas, and thus Aluminium Coil Tubing is a convenient and effective solution to contemporary industrial requirements.
