Impex Tubes India is a well-known manufacturer and exporter of quality pipes and tubes, located in Mumbai, India, catering to both domestic and overseas markets. Among their wide range of products, Aluminium Boiler Tubing is especially designed for heavy-duty high-temperature and pressure usage in heating systems. Produced to precise standards and according to industry norms, these tubes provide superior heat conductivity, corrosion resistance, and strength. Impex Tubes India specializes in quality focus, providing Aluminium Boiler Tubing solutions with efficiency, safety, and durability in a variety of industrial and commercial boiler systems.
Aluminium Boiler Tubing is usually produced from high-quality alloys such as 6061 or 6063, which contain more than 95% aluminium and magnesium and silicon as major alloying components. This blend provides a balanced combination of strength, corrosion resistance, and thermal conductivity. These tubes usually have tensile strengths ranging from 150–310 MPa and have good elongation for increased durability under pressure. The low weight of aluminium, coupled with superior heat transfer properties, renders it suitable for boiler use. Aluminium Boiler Tubing is also resistant to scaling and oxidation at high temperatures, providing long-term dependability in heating applications.
Standards : ASTM B345, B241, B429 / ASME SB345, SB241, SB429
Standard : AMS QQ-A-200/8, AMS QQ-A-200/9, AMS 4160/4161/4172
Size : 8 (1-1/2″ / 1.900″)
Outer Diameter : 1″ through 16″
Length : Double Random, Single Random, Cut Length
Thickness : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
End : Plain End, Beveled End, Threaded
ASTM B429 / ASME SB429 – Standard Specification for Aluminum-Alloy Extruded Structural Tube and Tube
EN AW-AlMg1SiCu – Standard Specification for Aluminum and Aluminum-Alloy Round Tube
ISO AlMg1SiCu – Standard Specification for Aluminum and Aluminum-Alloy Cold / Hot Rolled Tubing
| Alloy | Fe | Si | Mg | Mn | Cu | Zn | Ti | Cr | Others | AI |
| 1100 (min) | 0.35 | 0.25 | 0.01 | 0.01 | 0.05 | 0.01 | 0.020 | Trace | 0.05 (each) | 99.60% |
| 1100 (max) | 0.50 | 0.35 | 0.03 | 0.05 | 0.20 | 0.05 | 0.030 | Trace | 0.15 (total) | remainder |
| 5083 | 0.40 max | 0.40 max | 4.0 / 4.90 | 0.40 / 1.0 | 0.10 max | 0.25 max | 0.15 max | 0.05 / 0.25 | 0.05 max | Bal |
| 6061 | 0.7 | 0.4-0.8 | 0.8-1.2 | 0.15 | 0.15-0.4 | 0.25 | 0.15 | 0.15-0.35 | 0.005/0.15 | Remainder |
| 6068 | 0.50 max | 0.7 – 1.3 | 0.06-1.20 | 0.40-1.00 | 0.10 max | 0.20 max | 0.10 max | 0.25 max | 0.05 max | Bal |
| 7075 min | 2.10 | 1.20 | 5.10 | 0.18 | ||||||
| 7075 max | 0.50 | 0.40 | 2.90 | 0.30 | 2.00 | 6.10 | 0.20 | 0.28 | 0.05 |
| Alloy | Temper | UTS(Mpa) | % Elongation | Tensile Strength | Hardness Brinell | Proof Stress | Yield Strength (PSI) | Shear Strength (PSI) | Brinell Hardness | |||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | ||||||||
| 1100 | O | 75 | 110 | 20 | 25 | 29 | ||||||
| H12 | 95 | 130 | 5 | 6 | 7 | |||||||
| H14 | 110 | 145 | 3 | 4 | 5 | |||||||
| H16 | 130 | 165 | 2 | 3 | 4 | |||||||
| H18 | 150 | — | 2 | 2 | 3 | |||||||
| 5083 | 12 Min % | 275 – 350 MPa | 75 HB | 125 Min MPa | ||||||||
| 6061 | – | 45,000 | 12 | 40,000 | 31,000 | 95 | ||||||
| 6082 | 8 | 295 | 95 | – | 240 | – | – | |||||
| 7075 T6, T651 | 11 | 83-572 | 73- 503 | 150 | ||||||||
| 7075 T73, T7351 | 13 | 73-503 | 63-434 | NA | ||||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Aluminium Boiler Tubing from Impex Tube India ensures you benefit from superior quality and reliability. Our tubing is manufactured using advanced techniques and high-grade alloys, offering excellent corrosion resistance and lightweight durability. We prioritize customer satisfaction, providing tailored solutions to meet your specific needs. With extensive industry experience, we guarantee optimal performance in various applications. Additionally, our commitment to environmental sustainability means our products are fully recyclable. Trust Impex Tube India for innovative, efficient, and high-performance aluminium boiler tubing that exceeds industry standards.
Impex Tube India, one of the largest suppliers of Aluminium Boiler Tubing in Mumbai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Aluminium Boiler Tubing to meet your specific requirements. Our team at Impex Tube India is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@impextubeind.com.
| Grade | UNS | USA | Japan | France | ISO | WNR | EN | DIN | ISO | BS (OLD) |
| 1100 | A91100 | AA1100 | JIS A1100P | NF 1100 | Al 99.0 Cu. | – | – | – | – | – |
| 6082 | A96082 | AA6082 | – | – | – | 3.2315 | AW-6082 | AlMgSi1 | AlSi1MgMn | HE30 |
| 5083 | A95083 | 5083 | – | – | AlMg4,5Mn0,7 | 3.3547 | AW-AlMg4,5Mn0,7 | AlMg4,5Mn | – | – |
| 6061 | A96061 | AA6061 | – | – | – | 3.3211 | AW-AlMg1SiCu EN AW-6061 | AlMgSiCu | AlMg1SiCu | HE20 |
| 7075 | A97075 | 7075 | 3.4365 | ENAW-AlZn5.5MgCu EN AW-7075 | AlZnMgCu1.5 | AlZn6MgCu | 7075 L95 L96, V95 |
Aluminium Boiler Tubing finds extensive applications in industries requiring efficient heat transfer and corrosion resistance. In power plants and industrial heating systems, it is an integral part in boilers, economizers, and heat exchangers. The HVAC industry applies it to hot water systems and heating coils because of its superior thermal conductivity and light weight. In marine and chemical industries, it facilitates heating operations in corrosive environments. Aluminium Boiler Tubing is also utilized in pharmaceuticals and food processing sectors where clean and efficient heat systems are needed. Its ease of maintenance, durability, and easy installation make it a choice in many heat-intensive processes.
