Home > Stainless Steel > Stainless Steel 316H Heat Exchanger Tubing
Impex Tube India is one of the premier manufacturers and suppliers in Mumbai, India, known to supply high-quality stainless steel piping solutions for industrial use. One of its specialty products is Stainless Steel 316H Heat Exchanger Tubing, acclaimed for exceptional high-temperature strength, corrosion resistance, and greater durability. These tubes are specifically engineered for demanding thermal systems and are perfect for effective heat transfer in demanding operating conditions. Impex Tube India guarantees precision engineering, international standard compliance, and superior performance, which makes 316H heat exchanger tubing a trustworthy option for the power, petrochemical, chemical, and oil & gas sectors.
Stainless Steel 316H Heat Exchanger Tubing is a high-carbon version of 316 stainless steel, specifically designed for applications at high temperatures. It contains 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and 0.04–0.10% carbon, which increases creep resistance and high-temperature strength. These tubes have mechanical properties like a tensile strength of 515–585 MPa, yield strength of approximately 205–240 MPa, and elongation of about 35–40%. The extra molybdenum enhances pitting and crevice corrosion resistance, making these tubes appropriate for corrosive and high-stress environments where thermal efficiency and strength are both needed.
Range : 10 mm OD to 50.8 mm OD
Outer Diameter : 6.00 mm to 101.60 mm
Wall Thickness : 0.70 mm to 8.00 mm
Length : up to 20 m (65.62 ft) Length & Customed Required Length
Specifications : ASTM A 213, A 268, A 269, A 789, Equivalent to ASME, EN, JIS Etc.
| Element | SS 316H |
| C | 0.10 max |
| Mn | 2.0 max |
| Si | 0.75 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 16.00 – 18.00 |
| Mo | 2.00 – 3.00 |
| Ni | 10.00 – 14.00 |
| Fe | 68.89 min |
| Element | SS 316H |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 316H Heat Exchanger Tubing from Impex Tube India ensures superior quality and reliability. With expertise in precision manufacturing, Impex Tube India provides 316H tubing that offers exceptional strength and corrosion resistance, especially in high-temperature and corrosive environments. Their products meet stringent industry standards, ensuring long-lasting performance in demanding applications. Additionally, Impex Tube India is known for timely deliveries, excellent customer service, and customized solutions, making them a trusted supplier for industries like chemical processing, power generation, and oil and gas.
Impex Tube India, one of the largest suppliers of Stainless Steel 316H Heat Exchanger Tubing in Mumbai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel 316H Heat Exchanger Tubing to meet your specific requirements. Our team at Impex Tube India is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@impextubeind.com.
| STANDARD | WERKSTOFF NR. | UNS | JIS |
| SS 316H | 1.4401 | S31609 | SUS 316H |
Stainless Steel 316H Heat Exchanger Tubing is commonly employed in processes requiring high mechanical strength and superior resistance to high temperatures and corrosive environments. In power plants, they are employed in superheaters, reheaters, and boiler systems because of their better performance under thermal stress. In the petrochemical and chemical industries, they are required in heat exchangers, condensers, and reactors working in corrosive and high-pressure environments. They are also used in oil & gas refineries, fertilizer plants, and marine engineering for effective heat transfer processes. They are durable, thermally conductive, and corrosion-resistant and thus suitable for long-term operation in critical systems.
