Home > Copper Nickel > Copper Nickel 90/10 Pipes
Impex Tube India, a leading manufacturer and supplier of superior quality pipes and tubes, such as Copper Nickel 90/10 Pipes, is headquartered in Mumbai. The Copper Nickel 90/10 Pipes have superior seawater corrosion, biofouling, and erosion resistance, and hence can be applied across a number of industrial and marine uses. Impex Tube India manufactures their Copper Nickel 90/10 Pipes with absolute precision, endurance, and adherence to global standards. They are trusted by various industries around the world and ensure reliable, long-term performance in applications where there is high corrosion resistance and strength required.
Copper Nickel 90/10 Pipes are made up of 90% copper and 10% nickel, with traces of iron and manganese, which improve their mechanical strength and corrosion resistance. The composition of the alloy provides Copper Nickel 90/10 Pipes superior resistance to seawater, brine, and other corrosive environments. These pipes have good tensile strength (approximately 275 MPa) and high stress durability mechanically. They also have good electrical and thermal conductivity, which makes them ideal for heat exchangers and systems that need strength as well as resistance to erosion and biofouling.
Specifications : ASTM / ASME SB 111 / 151 / 466
Standard : ASTM, ASME and API
Size : 1/2″ TO 6′ IN OD & NB IN Various SWG & SCH
Outer Diameter : 4.00 to 22.00 mm
Well Thickness : Between 0.15mm and 1.50 mm
Length : Single Random, Double Random & Required Length
Schedule : SCH20, SCh20, SCh30, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Types : Seamless / ERW / Welded / EFW / Fabricated / CDW
Form : Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes
End : Plain End, Beveled End, Treaded
Grades : Copper Nickel 90/10 (C70600 ), Cupro Nickel 70/30 (C71500), UNS C71640
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 90-10 | 88.6 min | 1.0 max | .05 max | 9-11 max | 1.8 max | 1 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Copper Nickel 90-10 | 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 90-1000 psi | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Copper Nickel 90/10 Pipes from Impex Tube India ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Impex Tube India, one of the largest suppliers of Copper Nickel 90/10 Pipes in Mumbai, India, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for copper nickel products in the region.
| ASTM B466 C70600 | JIS H 3300 C7060 | BS 2871 CN 102 | DIN 86019 CuNi10Fe1.6Mn 2.1972 | MIL-T-16420K C70600 | EEMUA 234 UNS 7060X | |
|---|---|---|---|---|---|---|
| Fe% | 1.0-1.8 | 1.0-1.8 | 1.0-2.0 | 1.5-1.8 | 1.0-1.8 | 1.5-2.0 |
| Ni% | 9.0-11.0 | 9.0-11.0 | 10.0-11.0 | 9.0-11.0 | 9.0-11.0 | 10.0-11.0 |
| Cu% | Balance | Cu+Ni +Fe+Mn Min.99.5 | Balance | Balance | Min.86.5 | Balance |
| Mn% | Max.1.0 | 0.2-1.0 | 0.5-1.0 | 0.5-1.0 | Max1.0 | 0.5-1.0 |
| Pb% | Max.0.02 | Max.0.05 | Max.0.01 | Max.0.03 | Max.0.02 | Max.0.01 |
| C% | Max.0.05 | Max.0.05 | Max.0.05 | Max.0.05 | Max.0.05 | |
| Zr% | Max.0.03 | |||||
| P% | Max.0.02 | Max.0.02 | Max.0.02 | Max.0.02 | ||
| S% | Max.0.02 | Max.0.05 | Max.0.015 | Max.0.02 | Max.0.02 | |
| Zn% | Max.0.50 | Max.0.50 | Max.0.15 | Max.0.05 | Max.0.20 | |
| Others | Max.0.30 | Max.0.30 | Max.0.30 |
Yes, we offer custom sizes for Copper Nickel 90/10 Pipes to meet your specific requirements. Our team at Impex Tube India is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@impextubeind.com.
| Dimension Tolerance | |||||
| Material | Ultimate Tensile Strength1000 psi (MPa) | Yield Strength 0.5% Ext.under Load 1000 psi (MPa) | YElongation % in 2 in. | Fatigue Strength (10×7 cycles) 1000 psi (MPa) | Burst Pressure* 1000 psi (MPa) |
| Copper-brazed Steel | 48-55 (0.330-0.380) | 28-34 (0.190-0.235) | 30-40 | 30 (0.210) | 19.5 (0.135) |
| C12200-Phosphorus deoxidized Copper | 32-38 (0.220-0.265) | 10-14 (0.070-0.100) | 45-60 | 10 (0.070) | 12 ( 0.083) |
| C70600-Copper Nickel 90-10 | 48-54 (0.330-0.370) | 16-22 (0.110-0.150) | 40-55 | 15 (0.100) | 19 (0.130) |
Copper Nickel 90/10 Pipes are extensively utilized in marine and offshore environments because of their corrosion resistance against seawater and biofouling. The pipes are used extensively in shipbuilding, desalination plants, and offshore oil platforms for seawater cooling systems, heat exchangers, and condenser tubes. In the petrochemical and chemical industries, they are utilized for the handling of corrosive fluids and brine solutions. Moreover, Copper Nickel 90/10 Pipes are used in industrial cooling systems, water treatment facilities, and hydraulic systems where corrosion resistance and strength are necessary to ensure long-term, dependable performance under harsh conditions.
